How to build an image classifier with greater than 97% accuracy

(This article first appeared in Free Code Camp)

Image classifiers are amazing.

How do you teach a computer to look at an image and correctly identify it as a flower? How do you teach a computer to see an image of a flower and then tell you exactly what species of flower it is when even you don’t know what species it is?

Let me show you!

This article will take you through the basics of creating an image classifier with PyTorch. You can imagine using something like this in a phone app that tells you the name of the flower your camera is looking at. You could, if you wanted, train this classifier and then export it for use in an application of your own.

What you do from here depends entirely on you and your imagination.

I put this article together for anyone out there who’s brand new to all of this and looking for a place to begin. It’s up to you to take this information, improve on it, and make it your own! Build an even better image classifier if you want to!

If you want to view the notebook, you can find it here.

Because this PyTorch image classifier was built as a final project for a Udacity program, the code draws on code from Udacity which, in turn, draws on the official PyTorch documentation. Udacity also provided a JSON file for label mapping. That file can be found in this GitHub repo.

Information about the flower data set can be found here. The data set includes a separate folder for each of the 102 flower classes. Each flower is labeled as a number and each of the numbered directories holds a number of .jpg files.

Let’s make an image classifier!



Because this is a neural network using a larger dataset than my CPU could handle in any reasonable amount of time, I went ahead and set up my image classifier in Google Colab. Colab is truly awesome because it provides free GPU. (If you’re new to Colab, check out this article on getting started with Google Colab!)

Because I was using Colab, I needed to start by importing PyTorch. You don’t need to do this if you aren’t using Colab.

*** UPDATE! (01/29)*** Colab now supports native PyTorch!!! You shouldn’t need to run the code below, but I’m leaving it up just in case anyone is having any issues!

Then, after having some trouble with Pillow (it’s buggy in Colab!), I just went ahead and ran this:

import PIL
print(PIL.PILLOW_VERSION)

If you get anything below 5.3.0, use the dropdown menu under “Runtime” to “Restart runtime” and run this cell again. You should be good to go!

You’ll want to be using GPU for this project, which is incredibly simple to set up on Colab. You just go to the “runtime” dropdown menu, select “change runtime type” and then select “GPU” in the hardware accelerator drop-down menu!



Then I like to run

train_on_gpu = torch.cuda.is_available()

if not train_on_gpu:
    print('Bummer!  Training on CPU ...')
else:
    print('You are good to go!  Training on GPU ...')

just to make sure it’s working. Then run

device = torch.device("cuda:0" if torch.cuda.is_available() else "cpu")

to define the device.

After this, import the files. There are a ton of ways to do this, including mounting your Google Drive if you have your dataset stored there, which is actually really simple. Even though I didn’t wind up finding that to be the most useful solution, I’m including that below, just because it’s so easy and useful.

from google.colab import drive
drive.mount('/content/gdrive')

Then you’ll see a link, click on that, allow access, copy the code that pops up, paste it in the box, hit enter, and you’re good to go! If you don’t see your drive in the side box on the left, just hit “refresh” and it should show up.

(Run the cell, click the link, copy the code on the page, paste it in the box, hit enter, and you’ll see this when you’ve successfully mounted your drive):



It’s actually super easy!

However, if you’d rather download a shared zip file link (this wound up being easier and faster for this project), you can use:

!wget
!unzip

For example:

!wget -cq https://s3.amazonaws.com/content.udacity-data.com/courses/nd188/flower_data.zip
!unzip -qq flower_data.zip

That will give you Udacity’s flower data set in seconds!

(If you’re uploading small files, you can just upload them directly with some simple code. However, if you want to, you can also just go to the left side of the screen and click “upload files” if you don’t feel like running some simple code to grab a local file.)



After loading the data, I imported the libraries I wanted to use for this image classifier:

%matplotlib inline
%config InlineBackend.figure_format = 'retina'

import time
import json
import copy

import matplotlib.pyplot as plt
import seaborn as sns
import numpy as np
import PIL

from PIL import Image
from collections import OrderedDict

import torch
from torch import nn, optim
from torch.optim import lr_scheduler
from torch.autograd import Variable
import torchvision
from torchvision import datasets, models, transforms
from torch.utils.data.sampler import SubsetRandomSampler
import torch.nn as nn
import torch.nn.functional as F

Next come the data transformations! You want to make sure to use several different types of transformations on your training set in order to help your program learn as much as it can. You can create a more robust model by training it on flipped, rotated, and cropped images.

The means that standard deviations are provided to normalize the image values before passing them to our network, but they can also be found by looking at the mean and standard deviation values of the different dimensions of the image tensors. The official documentation is incredibly helpful here!

For my image classifier, I kept it simple with:

data_transforms = {
    'train': transforms.Compose([
        transforms.RandomRotation(30),
        transforms.RandomResizedCrop(224),
        transforms.RandomHorizontalFlip(),
        transforms.ToTensor(),
        transforms.Normalize([0.485, 0.456, 0.406],
                             [0.229, 0.224, 0.225])
    ]),
    'valid': transforms.Compose([
        transforms.Resize(256),
        transforms.CenterCrop(224),
        transforms.ToTensor(),
        transforms.Normalize([0.485, 0.456, 0.406],
                             [0.229, 0.224, 0.225])
    ])
}

# Load the datasets with ImageFolder
image_datasets = {x: datasets.ImageFolder(os.path.join(data_dir, x),
                                          data_transforms[x])
                  for x in ['train', 'valid']}

# Using the image datasets and the trainforms, define the dataloaders
batch_size = 64
dataloaders = {x: torch.utils.data.DataLoader(image_datasets[x], batch_size=batch_size,
                                             shuffle=True, num_workers=4)
              for x in ['train', 'valid']}

class_names = image_datasets['train'].classes

dataset_sizes = {x: len(image_datasets[x]) for x in ['train', 'valid']}
class_names = image_datasets['train'].classes

As you can see above, I also defined the batch size, data loaders, and class names in the code above.

To take a very quick look at the data and check my device, I ran:

print(dataset_sizes)
print(device)

{'train': 6552, 'valid': 818}
cuda:0

Next, we need to do some mapping from the label number and the actual flower name. Udacity provided a JSON file for this mapping to be done simply.

with open('cat_to_name.json', 'r') as f:
    cat_to_name = json.load(f)

In order to test the data loader, run:

images, labels = next(iter(dataloaders['train']))
rand_idx = np.random.randint(len(images))
# Print(rand_idx)
print("label: {}, class: {}, name: {}".format(labels[rand_idx].item(),
                                               class_names[labels[rand_idx].item()],
                                               cat_to_name[class_names[labels[rand_idx].item()]]))

Now it starts to get even more exciting! A number of models in the last several years have been created by people far, far more qualified than most of us for reuse in computer vision problems. PyTorch makes it easy to load pre-trained models and build on them, which is exactly what we’re going to do for this project. The choice of model is entirely up to you!

Some of the most popular pre-trained models that work well for image classifiers, like ResNet, AlexNet, and VGG, come from the ImageNet Challenge. These pre-trained models allow others to quickly obtain cutting-edge results in computer vision without needing such large amounts of computer power, patience, and time. I actually had great results with DenseNet and decided to use DenseNet161, which gave me very good results relatively quickly.

You can quickly set this up by running

model = models.densenet161(pretrained=True)

but it might be more interesting to give yourself a choice of model, optimizer, and scheduler. In order to set up a choice in architecture, run

model_name = 'densenet' #vgg
if model_name == 'densenet':
    model = models.densenet161(pretrained=True)
    num_in_features = 2208
    print(model)
elif model_name == 'vgg':
    model = models.vgg19(pretrained=True)
    num_in_features = 25088
    print(model.classifier)
else:
    print("Unknown model, please choose 'densenet' or 'vgg'")

which allows you to quickly set up an alternate model.

After that, you can start to build your classifier, using the parameters that work best for you. I went ahead and built

for param in model.parameters():
    param.requires_grad = False

def build_classifier(num_in_features, hidden_layers, num_out_features):

    classifier = nn.Sequential()
    if hidden_layers == None:
        classifier.add_module('fc0', nn.Linear(num_in_features, 102))
    else:
        layer_sizes = zip(hidden_layers[:-1], hidden_layers[1:])
        classifier.add_module('fc0', nn.Linear(num_in_features, hidden_layers[0]))
        classifier.add_module('relu0', nn.ReLU())
        classifier.add_module('drop0', nn.Dropout(.6))
        classifier.add_module('relu1', nn.ReLU())
        classifier.add_module('drop1', nn.Dropout(.5))
        for i, (h1, h2) in enumerate(layer_sizes):
            classifier.add_module('fc'+str(i+1), nn.Linear(h1, h2))
            classifier.add_module('relu'+str(i+1), nn.ReLU())
            classifier.add_module('drop'+str(i+1), nn.Dropout(.5))
        classifier.add_module('output', nn.Linear(hidden_layers[-1], num_out_features))

    return classifier

which allows for an easy way to change the number of hidden layers that I’m using, as well as quickly adjusting the dropout rate. You may decide to add additional ReLU and dropout layers in order to more finely hone your model.

Next, work on training your classifier parameters. I decided to make sure I only trained the classifier parameters here while having feature parameters frozen. You can get as creative as you want with your optimizer, criterion, and scheduler. The criterion is the method used to evaluate the model fit, the optimizer is the optimization method used to update the weights, and the scheduler provides different methods for adjusting the learning rate and step size used during optimization.

Try as many options and combinations as you can to see what gives you the best result. You can see all of the official documentation here. I recommend taking a look at it and making your own decisions about what you want to use. You don’t literally have an infinite number of options here, but it sure feels like it once you start playing around!

hidden_layers = None

classifier = build_classifier(num_in_features, hidden_layers, 102)
print(classifier)

# Only train the classifier parameters, feature parameters are frozen
if model_name == 'densenet':
    model.classifier = classifier
    criterion = nn.CrossEntropyLoss()
    optimizer = optim.Adadelta(model.parameters())
    sched = optim.lr_scheduler.StepLR(optimizer, step_size=4)
elif model_name == 'vgg':
    model.classifier = classifier
    criterion = nn.NLLLoss()
    optimizer = optim.Adam(model.classifier.parameters(), lr=0.0001)
    sched = lr_scheduler.StepLR(optimizer, step_size=4, gamma=0.1)
else:
    pass

Now it’s time to train your model.

# Adapted from https://pytorch.org/tutorials/beginner/transfer_learning_tutorial.html

def train_model(model, criterion, optimizer, sched, num_epochs=5):
    since = time.time()

best_model_wts = copy.deepcopy(model.state_dict())
    best_acc = 0.0

for epoch in range(num_epochs):
        print('Epoch {}/{}'.format(epoch+1, num_epochs))
        print('-' * 10)

# Each epoch has a training and validation phase
        for phase in ['train', 'valid']:
            if phase == 'train':
                model.train()  # Set model to training mode
            else:
                model.eval()   # Set model to evaluate mode

running_loss = 0.0
            running_corrects = 0

# Iterate over data.
            for inputs, labels in dataloaders[phase]:
                inputs = inputs.to(device)
                labels = labels.to(device)

# Zero the parameter gradients
                optimizer.zero_grad()

# Forward
                # track history if only in train
                with torch.set_grad_enabled(phase == 'train'):
                    outputs = model(inputs)
                    _, preds = torch.max(outputs, 1)
                    loss = criterion(outputs, labels)

# Backward + optimize only if in training phase
                    if phase == 'train':
                        #sched.step()
                        loss.backward()

                        optimizer.step()

# Statistics
                running_loss += loss.item() * inputs.size(0)
                running_corrects += torch.sum(preds == labels.data)

epoch_loss = running_loss / dataset_sizes[phase]
            epoch_acc = running_corrects.double() / dataset_sizes[phase]

print('{} Loss: {:.4f} Acc: {:.4f}'.format(
                phase, epoch_loss, epoch_acc))

# Deep copy the model
            if phase == 'valid' and epoch_acc > best_acc:
                best_acc = epoch_acc
                best_model_wts = copy.deepcopy(model.state_dict())

print()

time_elapsed = time.time() - since
    print('Training complete in {:.0f}m {:.0f}s'.format(
        time_elapsed // 60, time_elapsed % 60))
    print('Best val Acc: {:4f}'.format(best_acc))

# Load best model weights
    model.load_state_dict(best_model_wts)

    return model

epochs = 30
model.to(device)
model = train_model(model, criterion, optimizer, sched, epochs)

I wanted to be able to monitor my epochs easily and also keep track of the time elapsed as my model was running. The code above includes both, and the results are pretty good! You can see that the model is quickly learning and the accuracy on the validation set quickly reached over 95% by epoch 7!

Epoch 1/30
----------
train Loss: 2.4793 Acc: 0.4791
valid Loss: 0.9688 Acc: 0.8191

Epoch 2/30
----------
train Loss: 0.8288 Acc: 0.8378
valid Loss: 0.4714 Acc: 0.9010

Epoch 3/30
----------
train Loss: 0.5191 Acc: 0.8890
valid Loss: 0.3197 Acc: 0.9181

Epoch 4/30
----------
train Loss: 0.4064 Acc: 0.9095
valid Loss: 0.2975 Acc: 0.9169

Epoch 5/30
----------
train Loss: 0.3401 Acc: 0.9214
valid Loss: 0.2486 Acc: 0.9401

Epoch 6/30
----------
train Loss: 0.3111 Acc: 0.9303
valid Loss: 0.2153 Acc: 0.9487

Epoch 7/30
----------
train Loss: 0.2987 Acc: 0.9298
valid Loss: 0.1969 Acc: 0.9584

...

Training complete in 67m 43s
Best val Acc: 0.973105

You can see that running this code on Google Colab with GPU took just over an hour.

Now it’s time for evaluation

model.eval()

accuracy = 0

for inputs, labels in dataloaders['valid']:
    inputs, labels = inputs.to(device), labels.to(device)
    outputs = model(inputs)

    # Class with the highest probability is our predicted class
    equality = (labels.data == outputs.max(1)[1])

# Accuracy = number of correct predictions divided by all predictions
    accuracy += equality.type_as(torch.FloatTensor()).mean()

print("Test accuracy: {:.3f}".format(accuracy/len(dataloaders['valid'])))

Test accuracy: 0.973

It’s important to save your checkpoint

model.class_to_idx = image_datasets['train'].class_to_idx

checkpoint = {'input_size': 2208,
              'output_size': 102,
              'epochs': epochs,
              'batch_size': 64,
              'model': models.densenet161(pretrained=True),
              'classifier': classifier,
              'scheduler': sched,
              'optimizer': optimizer.state_dict(),
              'state_dict': model.state_dict(),
              'class_to_idx': model.class_to_idx
             }

torch.save(checkpoint, 'checkpoint.pth')

You don’t have to save all of the parameters, but I’m including them here as an example. This checkpoint specifically saves the model with a pre-trained densenet161 architecture, but if you want to save your checkpoint with the two-choice option, you can absolutely do that. Simply adjust the input size and model.

Now you’re able to load your checkpoint. If you’re submitting your project into the Udacity workspace, things can get a little tricky. Here’s some help with troubleshooting your checkpoint load.

You can check your keys by running

ckpt = torch.load('checkpoint.pth')
ckpt.keys()

Then load and rebuild your model!

def load_checkpoint(filepath):
    checkpoint = torch.load(filepath)
    model = checkpoint['model']
    model.classifier = checkpoint['classifier']
    model.load_state_dict(checkpoint['state_dict'])
    model.class_to_idx = checkpoint['class_to_idx']
    optimizer = checkpoint['optimizer']
    epochs = checkpoint['epochs']

    for param in model.parameters():
        param.requires_grad = False

    return model, checkpoint['class_to_idx']

model, class_to_idx = load_checkpoint('checkpoint.pth')

Want to keep going? It’s a good idea to do some image preprocessing and inference for classification. Go ahead and define your image path and open an image:

image_path = 'flower_data/valid/102/image_08006.jpg'
img = Image.open(image_path)

Process your image and take a look at a processed image:

def process_image(image):
    ''' Scales, crops, and normalizes a PIL image for a PyTorch model,
        returns an Numpy array
    '''
    # Process a PIL image for use in a PyTorch model
    # tensor.numpy().transpose(1, 2, 0)
    preprocess = transforms.Compose([
        transforms.Resize(256),
        transforms.CenterCrop(224),
        transforms.ToTensor(),
        transforms.Normalize(mean=[0.485, 0.456, 0.406],
                             std=[0.229, 0.224, 0.225])
    ])
    image = preprocess(image)
    return image

def imshow(image, ax=None, title=None):
    """Imshow for Tensor."""
    if ax is None:
        fig, ax = plt.subplots()

    # PyTorch tensors assume the color channel is the first dimension
    # but matplotlib assumes is the third dimension
    image = image.numpy().transpose((1, 2, 0))

    # Undo preprocessing
    mean = np.array([0.485, 0.456, 0.406])
    std = np.array([0.229, 0.224, 0.225])
    image = std * image + mean

    # Image needs to be clipped between 0 and 1 or it looks like noise when displayed
    image = np.clip(image, 0, 1)

    ax.imshow(image)

    return ax

with Image.open('flower_data/valid/102/image_08006.jpg') as image:
    plt.imshow(image)

model.class_to_idx = image_datasets['train'].class_to_idx

Thank you for reading!
